99.99% Purity Red Copper Wire Mesh , EMF Shielding Copper Woven Mesh

Ask Lasest Price
Brand Name :	BJPFM
Model Number :	PFM - Woven Copper Wire Mesh
Certification :	SGS
Price :	Negotiate
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	500 Roll/Rolls per Week
Delivery Time :	7-10 work days

Add to Cart

Product Details
Company Profile

99.99% Purity Red Copper Wire Mesh , EMF Shielding Copper Woven Mesh

High Quality Direct Factory Price Pure 99.99% Woven Red Copper Wire Mesh

1. Woven Red Copper Wire Mesh Description

Red copper wire mesh is a high-purity copper mesh with a copper content of 99.9 %, which fully reflects the various characteristics of copper, extremely high electrical conductivity (after gold and silver), and good shielding performance.
Copper wire mesh is widely used in the shielding networks. In addition, the surface of copper is easily oxidized to form a dense oxide layer, which can effectively increase the rust resistance of the copper mesh, so it is sometimes used to filter corrosive gases and liquids.

99.99% Purity Red Copper Wire Mesh , EMF Shielding Copper Woven Mesh

2. Woven Red Copper Wire Mesh Features

1. Non-magnetic, wear resistance

2. Acid and alkali resistance, good ductility

3. Good conductivity, good heat transfer performance

4. EMF shielding

99.99% Purity Red Copper Wire Mesh , EMF Shielding Copper Woven Mesh

3. Woven Red Copper Wire Mesh Specification

**Avaiable Sizes**
Item	Mesh/Inch	Diameter		Opening		Weight
Item	Mesh/Inch	mm	inch	mm	inch	kg/m2
PFM-01	1	3	0.118	22.4	0.882	4.86
PFM-02	2	1.5	0.059	11.2	0.441	2.43
PFM-03	3	1.2	0.047	7.27	0.286	2.33
PFM-04	4	1	0.039	5.35	0.211	2.16
PFM-05	5	1	0.039	4.08	0.161	2.70
PFM-06	6	0.9	0.035	3.33	0.131	2.62
PFM-07	7	0.8	0.031	2.83	0.111	2.42
PFM-08	8	0.8	0.031	2.38	0.094	2.76
PFM-09	10	0.6	0.024	1.94	0.076	1.94
PFM-10	12	0.55	0.022	1.57	0.062	1.96
PFM-11	14	0.5	0.02	1.31	0.052	1.89
PFM-12	16	0.5	0.02	1.09	0.043	2.16
PFM-13	18	0.5	0.02	0.91	0.036	2.43
PFM-14	20	0.4	0.016	0.87	0.034	1.73
PFM-15	20	0.45	0.018	0.82	0.032	2.19
PFM-16	24	0.35	0.014	0.71	0.028	1.59
PFM-17	26	0.3	0.012	0.68	0.027	1.26
PFM-18	28	0.3	0.012	0.61	0.024	1.36
PFM-19	30	0.25	0.01	0.6	0.023	1.01
PFM-20	40	0.2	0.008	0.44	0.017	0.86
PFM-21	50*	0.18	0.007	0.33	0.013	0.87
PFM-22	60	0.16	0.006	0.26	0.01	0.83
PFM-23	60	0.19	0.007	0.23	0.009	1.17
PFM-24	70	0.12	0.005	0.24	0.01	0.54
PFM-25	80	0.12	0.005	0.2	0.008	0.62
PFM-26	80	0.13	0.005	0.19	0.007	0.73
PFM-27	100*	0.1	0.004	0.15	0.006	0.54
PFM-28	100	0.11	0.004	0.14	0.006	0.65
PFM-29	104	0.06	0.002	0.18	0.007	0.20
PFM-30	120*	0.09	0.004	0.12	0.005	0.52
PFM-31	120*	0.058	0.002	0.15	0.006	0.22
PFM-32	120*	0.08	0.003	0.13	0.005	0.41
PFM-33	140	0.07	0.003	0.11	0.004	0.37
PFM-34	145	0.045	0.002	0.13	0.005	0.16
PFM-35	150*	0.06	0.002	0.11	0.004	0.29
PFM-36	150*	0.05	0.002	0.12	0.005	0.20
PFM-37	160	0.05	0.002	0.11	0.004	0.22
PFM-38	160	0.04	0.002	0.12	0.005	0.14
PFM-39	160	0.035	0.001	0.12	0.005	0.11
PFM-40	165	0.05	0.002	0.1	0.004	0.22
PFM-41	180	0.05	0.002	0.09	0.004	0.24
PFM-42	180	0.04	0.002	0.1	0.004	0.16
PFM-43	200*	0.053	0.002	0.07	0.003	0.30
PFM-44	200*	0.05	0.002	0.08	0.003	0.27
PFM-45	200*	0.04	0.002	0.09	0.003	0.17
PFM-46	220	0.05	0.002	0.07	0.003	0.30
PFM-47	230	0.035	0.001	0.08	0.003	0.15
PFM-48	230	0.03	0.001	0.08	0.003	0.11
PFM-49	250	0.04	0.002	0.06	0.002	0.22
PFM-50	250	0.035	0.001	0.07	0.003	0.17
PFM-51	250	0.03	0.001	0.07	0.003	0.12
PFM-52	270	0.035	0.001	0.06	0.002	0.18
PFM-53	270	0.03	0.001	0.06	0.003	0.13
PFM-54	280	0.035	0.001	0.06	0.002	0.19
PFM-55	300	0.03	0.001	0.05	0.002	0.15

4. Woven Red Copper Wire Mesh Applications

Copper wire mesh with large mesh is generally used for decoration or protection; the copper mesh with small mesh is also called copper wire cloth, and some people call it a fine copper wire mesh, which has more functions, eg: Copper mesh Rf shielding

Copper mesh Rf shielding:
It can be used as the shielding screen in the cable circuits, laboratories, and computer rooms.
Widely used in the power sector, aerospace, information industry and military for RFI and EMI shielding.
It can be used as the faraday cage.

1> RFI/EMI/RF Shielding
2> Electronic information security
3> Faraday Cages
4> Power generation
5> Insect Screens
6> Outer space exploration and research
7> Fireplace Screen
8> Electronic security
